RD RK6006-C 60 V 6 A Programmable DC Bench Power Supply

The RD RK6006-C is the enclosed bench version of the RK6006 programmable DC step-down supply family. It is intended for regulated DC output in electronics development, repair benches, battery-related work and controlled device testing when a suitable upstream DC source is provided.

Electrical Specifications

• Input voltage range: 12 to 68.00 V DC.
• Adjustable output voltage: 0 to 60.00 V DC.
• Adjustable output current: 0 to 6.000 A.
• Maximum output power: 360 W.
• Listed output-voltage accuracy: ±(0.3% + 3 digits).
• Listed output-current accuracy: ±(0.5% + 5 digits).
• Typical listed output ripple: 100 mV peak-to-peak.

Controls and Protection

• 1.54-inch 240 x 240 colour display with six brightness levels.
• Temperature protection is listed above 90 C.
• Cooling fan is listed to start above 5 A output current or above 65 C system temperature.
• As a buck supply, the available output voltage must remain below the input voltage; choose a suitable upstream DC supply for the required output.

RK6006-C Package Note

• This listing is for the RK6006-C option, not the standalone RK6006 or RK6006-BT module.
• According to the matched source, RK6006-C does not include an input power cable or external temperature-sensor cable. Review the product images and prepare compatible accessories where required.
• Listed controller dimensions: approximately 79 x 43 x 54 mm.
• Verify polarity, input range, output limits and load wiring before powering a device. Do not connect the output to AC mains.
